ICB18L50F12NOM1

Inductive proximity sensor, M18 Nickel-Plated Brass, M12 plug, Sn 12mm, Quasi-flush mount, Long body, NPN NO output, Supply voltage 10-36Vdc, Max output current 200 mA, Max switching frequency 1,5 kHz, Operating temperature -25C - +70C, IP67

• Sensing distance: 12 to 20 mm

• Quasi-flush or non-flush mountable

• Short or long body versions

• Rated operational voltage (Ub): 10 - 36 VDC

• Output: DC 200 mA, NPN or PNP

• Normally open or Normally closed

• LED indication for output ON, short-circuit and overload

• Protection: reverse polarity, short circuit, transients

• Cable or M12 plug versions

• According to IEC 60947-5-2

• Setup indicator

• Laser engraved on front cap, permanently legible

• CSA certified for Hazardous Locations
