Inductive proximity sensor, M30 Stainless steel, M12 plug, Sn 15mm, Non-Flush mount, Long body, PNP NC output, Supply voltage 10-36Vdc, Max output current 200 mA, Max switching frequency 1 kHz, Operating temperature -40C - +80C, IP67, IP68, IP69K, Ecolab
• Sensing distance: 10 to 22 mm
• Flush or non-flush mountable
• Short or long body versions
• Rated operational voltage (Ub): 10 - 36 VDC
• Output: DC 200 mA, NPN or PNP
• Normally open or normally closed
• LED indication for output ON, short-circuit and overload
• Protection: reverse polarity, short circuit and transients
• M12 plug version
• According to IEC 60947-5-2
• High-pressure washdown resistant
• Ecolab certified, FDA-certified plastic
• Laser engraved on the housing, permanently legible
• Extended temperature range: -40°C...+85°C
• CSA certified for Hazardous Locations
